Application：

Stator I.D.：50~200 mm

Stack Height：Max. 500 mm

Specifications：

Operation Method：Pneumatic

Dimension：According To The Specification Of Stator.

Weight：According To The Specification Of Stator.

Function：

When forming mould, the wedge will be pressed out by the coil. The formed wedge will be pressed in slots by wedge machine when it’s close to the slots. It will prevent the coil from coming out.

Features：

1. Use by air pneumatic only without power.

2. Easy operation. Push by hand and Switch by foot.

3. Simple Structure.
